Electronic Motor Protection Relay eMPR300D (1-5.5 A)

Description

eMPR300D Electronic Motor Protection Relay with inbuilt display - Aux Supply 85-265V AC, Thermal O/L Range 1-5.5 A, Device Code 37, 46, 49, 51LR, 51, 64, One solution for both EOLR and EOCR applications, Protections: Overload, Locked Rotor, Single Phasing, Current Unbalance, Under Current, Dry Run Protection, Earth Fault, Phase Sequence Reversal, Overcurrent, 7 Segment LED Display; Inbuilt CT's (1 A to 88 A); 5 trip records; Test facility; Site Selectable - Fail-safe / Non Fail-safe mode; Selectable trip class - 10A, 10, 20 and 30 as per IEC 60947-4-1

Specifications
