Lauritz Knudsen 4000 Series kWh LCD Energy Meter Class 0.5 with RS485

Description

Lauritz Knudsen 4000 Series kWh LCD Energy Meter Class 0.5 with RS485 (Cat. No. WC4000210000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 0.5; Display: LCD; Communication: RS485; Energy Selection: kWh or kVAh, site selectable; Parameters: Site selectable kWh / kVA / PF / W; old energy; Auto Scaling: Kilo, Mega and Giga; Lifetime kWh Display Note: For 415 V LL and CT primary value of 400 and below. Catalogue MRP Rs. 5,285 per unit; standard package 1.
