Lauritz Knudsen 4000 Series kWh LCD Energy Meter Class 1 with RS485

Description

Lauritz Knudsen 4000 Series kWh LCD Energy Meter Class 1 with RS485 (Cat. No. WC4000110000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 1; Display: LCD; Communication: RS485; Energy Selection: kWh or kVAh, site selectable; Parameters: Site selectable kWh / kVA / PF / W; old energy; Auto Scaling: Kilo, Mega and Giga; Lifetime kWh Display Note: For 415 V LL and CT primary value of 400 and below. Catalogue MRP Rs. 4,380 per unit; standard package 1.

Specifications
