Lauritz Knudsen 4040 Series Dual Source LCD Basic Multifunction Meter Class 0.5 with RS485

Description

Lauritz Knudsen 4040 Series Dual Source LCD Basic Multifunction Meter Class 0.5 with RS485 (Cat. No. WC4040210000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 0.5; Display: LCD; Communication: RS485; DG Sensing Input: 230 V AC; Indication: Discrete LED for EB and DG; Power Factor: True PF or displacement PF, site selectable; Energy Selection: kWh or kVAh, site selectable; Display Parameters: kW, kVA, PF, run hours, kWh (EB and DG), old energy, site selectable kWh / kVAh; Communication Parameters: V, A, F, kW, kVA, PF, run hours, kWh (EB and DG), old energy, site selectable kWh / kVAh. Catalogue MRP Rs. 8,915 per unit; standard package 1.
