Lauritz Knudsen BB Series Three Pole (TP) 40A D-Curve Miniature Circuit Breaker

Description

Lauritz Knudsen BB Series Three Pole (TP) 40A D-Curve Miniature Circuit Breaker (Cat. No. BB30400D). Series: BB; Rated Current: 40 A; Poles: Three Pole (TP); Trip Curve: D; Modules: 3; Module Width: 17.5 mm; Standard: IS/IEC 60898; IS/IEC 60947-2; Breaking Capacity (IS/IEC 60898): 10 kA; Features: Individual pole contact indication; label holder; trip-free mechanism; bi-connect terminals; accessory fitment; no line-load bias. Catalogue MRP Rs. 3,415 per unit. Standard package 4.

Specifications
