Lauritz Knudsen dsine DY125U 63A 2 Pole MCCB

Description

Lauritz Knudsen dsine DY125U 63A 2 Pole MCCB (Cat. No. EM9098200H0). Type: DY125U; Rated Current: 63A; Poles: 2 Pole; Release Type: Thermal-Magnetic; Series: DY; Phase Barriers: Supplied; Suitable for Isolation: Yes; Frame Size: 2 Pole in 3 Pole frame size; Breaking Capacity Icu: 25kA at 240V AC, 50/60Hz; 10kA at 250V DC with 2 poles in series; Standard: IS/IEC 60947-2, IEC 60947-2 and EN 60947-2; Ics: 100% of Icu; Load-Line Bias: No; Indication: ON-TRIP-OFF; SS Enclosure: Common for 3P and 4P; Electrical and Mechanical Life: High. Catalogue MRP: 2820; standard package: 1.
