Lauritz Knudsen FN 250 TPN Sheet Steel Enclosure Switch Disconnector Fuse

Description

Lauritz Knudsen FN 250 TPN Sheet Steel Enclosure Switch Disconnector Fuse (Cat. No. SK904890000). Product Type: FN Switch-Disconnector-Fuse; Type: FN 250 TPN; Rated Current: 250A; Frame: Frame 3; Execution: Sheet Steel Enclosure; Suitable Fuse-Link: HN Size 1; Rated Voltage: 415V AC; Utilization Category: AC 23A; Key Features: Conforms to IEC 60947-3 and IS/IEC 60947-3, Door interlock and padlock facility, Telescopic shaft for depth adjustment, Phase barriers included, Spacious sheet steel enclosure, Separate cable gland box not required, Suitable for cylindrical/DIN fuse-link; Notes: HRC fuses excluded from price, Supplied without terminal shrouds, For 690V AC application, contact branch office, Enclosed units can be replaced with FN TPN SDF open-execution units, Replacement for FN 250 enclosed unit SK904890000 / SK956810000: order ST978950000; Suitable Fuse Current Range: 125 to 250A; Poles: TPN. Catalogue MRP Rs. 31,500 per unit; standard package 1.
