Lauritz Knudsen U-POWER OMEGA DigiCom Module Status Monitoring and Control

Description

Lauritz Knudsen U-POWER OMEGA DigiCom Module Status Monitoring and Control (Cat. No. CL918960000). Function: Status monitoring and control of up to 3 circuit breakers through MODBUS RTU protocol with RS 485 port; Digital Inputs: 9 (3 per circuit breaker); Relay Outputs: 6 (2 per circuit breaker); Input Voltage: 24V DC; Indicators: Input status, system status and output status indicators; Catalogue Note: CFI and RTC micro switches should be selected along with the ACB for optimal performance; also listed on catalogue page 79. Catalogue MRP: 33800; standard package: 1.
