Lauritz Knudsen U-POWER OMEGA UW1-20N 2000A 4 Pole Manual Draw-out ACB UW-MTX1G 690V AC

Description

Lauritz Knudsen U-POWER OMEGA UW1-20N 2000A 4 Pole Manual Draw-out ACB UW-MTX1G 690V AC (Cat. No. UW120NFD01800). Series: U-POWER OMEGA; Category: Air Circuit Breakers; Type: UW1-20N; Frame Size: 1; Rated Current: 2000A; Poles: 4 Pole; Operation: Manual; Version: Draw-out; Version Code: MDO; Rated Voltage: 690V AC; Breaking Capacity: 50kA at 415V AC; Protection and Control Unit: UW-MTX1G; Protection Functions: LSING; Setting Interface: BCD switches; Neutral Rating: 100%. Catalogue MRP: 610800; standard package: 1.

Specifications
