Lauritz Knudsen U-POWER OMEGA UW2-25N 2500A 3 Pole Manual Fixed ACB UW-MTX1G 690V AC

Description

Lauritz Knudsen U-POWER OMEGA UW2-25N 2500A 3 Pole Manual Fixed ACB UW-MTX1G 690V AC (Cat. No. UW225NXF01800). Series: U-POWER OMEGA; Category: Air Circuit Breakers; Type: UW2-25N; Frame Size: 2; Rated Current: 2500A; Poles: 3 Pole; Operation: Manual; Version: Fixed; Version Code: MF; Rated Voltage: 690V AC; Breaking Capacity: 50kA at 415V AC; Protection and Control Unit: UW-MTX1G; Protection Functions: LSING; Setting Interface: BCD switches. Catalogue MRP: 503800; standard package: 1.
