Lauritz Knudsen 4040 Series Dual Source LED Basic Multifunction Meter Class 1

Description

Lauritz Knudsen 4040 Series Dual Source LED Basic Multifunction Meter Class 1 (Cat. No. WL4040100000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 1; Display: LED; Communication: Not listed; DG Sensing Input: 230 V AC; Indication: Discrete LED for EB and DG; Power Factor: True PF or displacement PF, site selectable; Energy Selection: kWh or kVAh, site selectable; Display Parameters: kW, kVA, PF, run hours, kWh (EB and DG), old energy, site selectable kWh / kVAh; Communication Parameters: V, A, F, kW, kVA, PF, run hours, kWh (EB and DG), old energy, site selectable kWh / kVAh. Catalogue MRP Rs. 6,040 per unit; standard package 1.
