Lauritz Knudsen 41xx Series VAF + PF Meter Class 0.5

Description

Lauritz Knudsen 41xx Series VAF + PF Meter Class 0.5 (Cat. No. WL4110200000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 0.5; Display: LED; Communication: Not listed; Series Parameters: VLL, VLN, A, F, PF, On Hrs, RPM. Catalogue MRP Rs. 3,690 per unit; standard package 1.
