Lauritz Knudsen 4410 Series LED Multifunction Meter Class 0.5S with RS485

Description

Lauritz Knudsen 4410 Series LED Multifunction Meter Class 0.5S with RS485 (Cat. No. WL4410310000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Accuracy Class: 0.5S; Display: LED; Communication: RS485; Samples per Cycle: 128; Power Factor: True and displacement PF; Parameters: V, A, F, PF, kW, kVA, kVAr, kWh, kVAh, kVArh, run hours, on hours, phase angle, interruptions, THD, events (high-low), neutral current, K factor; Features: Dedicated buttons for direct access to basic, power and energy parameters. Catalogue MRP Rs. 15,480 per unit; standard package 1.

Specifications
