Lauritz Knudsen 6000 Series LCD Maximum Demand Controller Class 1 with RS485

Description

Lauritz Knudsen 6000 Series LCD Maximum Demand Controller Class 1 with RS485 (Cat. No. WC6000110000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Display: LCD; Accuracy Class: 1; Communication: RS485; Parameters: V, A, F, PF, kW, kVA, kVAr, kWh, kVAh, kVArh, run hours, on hours, phase angle, interruptions, THD, events (high-low), neutral current, K factor; Data Log Memory: 8 MB; Data Log Configuration: 29 parameters including kWh, demand and harmonics; minimum 1 minute interval; Relay Outputs: 4 for maximum demand controller; Time of Day: 6 slots; Demand Window: Block / sliding, site selectable; Demand Display: Running, maximum and prediction demand in single page window; Maximum Demand: With RTC; Individual Harmonics: Up to 31st order; Power Factor: True and displacement PF. Catalogue MRP Rs. 44,680 per unit; standard package 1.
