Lauritz Knudsen 6000 Series LED Maximum Demand Controller Class 0.5S with RS485

Description

Lauritz Knudsen 6000 Series LED Maximum Demand Controller Class 0.5S with RS485 (Cat. No. WL6000310000). Input Voltage Measurement Range: 50 - 520 V AC (P-P); Auxiliary Supply: 80 - 300 V AC / DC; CT Secondary: 1 A / 5 A, site selectable; Mounting: Flush, 96 x 96 mm; CT/PT: Site programmable; Display: LED; Accuracy Class: 0.5S; Communication: RS485; Parameters: V, A, F, PF, kW, kVA, kVAr, kWh, kVAh, kVArh, run hours, on hours, phase angle, interruptions, THD, events (high-low), neutral current, K factor; Data Log Memory: 8 MB; Data Log Configuration: 29 parameters including kWh, demand and harmonics; minimum 1 minute interval; Relay Outputs: 4 for maximum demand controller; Time of Day: 6 slots; Demand Window: Block / sliding, site selectable; Demand Display: Running, maximum and prediction demand in single page window; Maximum Demand: With RTC; Individual Harmonics: Up to 31st order; Power Factor: True and displacement PF. Catalogue MRP Rs. 47,175 per unit; standard package 1.

Specifications
